Panels:

• Mesh size 12.5 x 76.2mm – 4mm wire.

Manufactured to BS 4102 and galvanised to BS EN

10244-2:2001 class D.

Weld strength is 75% of the minimum tensile strength of the wire (tensile range 540-690 N/m2).

Posts:

• Dig-in posts. Post size varies with height (see table).

• Post material manufactured to BS EN 10210-2:1997 and galvanised to BS EN 10346:2009.

Supplied with plastic cap (size varies with height (see table)).

Fixings:

• Clamp Bar: 40 x 5mm (full length of mesh panel).

• M8 x (varies with post size) cup square security bolt.

• M8 shear nut with M8 washer.

Finishings:

Standard colour is RAL 6005 (Moss Green).

Other RAL colours available as special order, including marine grade coating.

Post Options:

Cranked posts (internal and external / top and bottom).

Face fix (for flush against walls).

Threaded insert posts.

Base-plated (flush to front, back or centrally) available as special order for installation onto concrete and other hard surfaces.
