Description

Product Technical Information

Panels:

• Mesh size 200 x 50mm.
• 1 x 6mm vertical and 2 x 8mm horizontal wire.
• Panels can be inverted to create flat top option.
• Manufactured to BS 4102 and galvanised to BS EN10244-2:2001 class D.
• Weld strength is 75% of the minimum tensile strength of the wire (tensile range 540-690 N/m2).

Posts:

• Dig-in posts. Post size varies with height (see table).

• Post material manufactured to BS EN 10210-2:1997 and galvanised to BS EN 10346:2009.
• Supplied with plastic cap (size varies with height (see table)).

Fixings:

• Clamp Bar: 40 x 5mm (full length of mesh panel).
• M8 washer.
• M8 x 40mm Button Head A2 Stainless Steel Shear Bolt.
  Rubber backstops are available for all fixings for anti-vibration.

Finishings:

• Panels & Posts are galvanised before being powder coated to BS EN 13438:2005 (min 100 micron).
• Standard colour is RAL 6005 (Moss Green).
• Other RAL colours available as special order, including marine grade coating.

PostOptions:

• Cranked posts (internal and external / top and bottom).
• Face fix (for flush against walls).
• Base-plated (flush to front, back or centrally) available as special order for installation onto concrete and other hard surfaces.
